New range of L-shaped ATEX heaters for tanks

02-04-2019

New range of L-shaped ATEX heaters for tanks

Resistencia Tope is developing a new range of L shape ATEX immersion heaters

After obtaining the ATEX certificate for heating gases, Resistencias Tope is developing a range of L-shaped ATEX heaters for large storage tanks.

These ATEX immersion heater are designed for being installed at the bottom of process tanks at ATEX /IECEx Zone 1 & Zone 2 hazardous areas.

Electrical flange immersion heaters are designed for heating or maintain constant temperature of liquids in static condition. These ATEX immersion heater are designed for being installed horizonatally at the bottom of process tanks at ATEX /IECEx Zone 1 & Zone 2 hazardous areas.

Features:

  • Explosion proof construction: II2G Ex db IIC T1…T6 Gb
  • Range of ambient temperature:-60C /+60C
  • IP65 junction box protection
  • Power: Up to:225kw
  • Lenght: Up to 4500mm
  • Standard elements available sheathed within: AISI 321, AISI 316, Incoloy800 and Inconel625
  • Multiple rows of elements for higher wattages
  • Flange mounted with removable stand pipe for an easy installation.

Aplications:

  • Storage tanks
  • Heating liquids in large tanks or vessels with low levels of product.
  • Heating liquids in underground tanks.
